Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 789
shown on opposite side of FG, where thecrank passes through the arc DJE during the exhaustperiod, with a positive exhaust lap of the size EF.AVhen the exhaust edge of the valve is line and line,this arc becom.es GFJ, or i8o°, and when a negative lap 760 LOCOMOTIVE ENGINEERING (clearance) occurs,… … FIG. 338. A CONVENIENT GAUGE FOR SETTING THEECCENTRIC CRANK In Fig. 337 the eccentric and admission valve circlesare shown at different cut-ofifs where each set of linesand circles is governed by the same explanation as thoseof Fig. 336, where the admission points S, S/ S^, S^, cor-respond to the…
Locomotives
