Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 791
762 LOCO^IOTIVE ENGINEERING … WALSCHAERT VALVE GEAR 763 points R, R\ R-, R\ etc. On OH we have the full travelvalve circle and OL the lap or radius of the lap circle,the latter being the same for all cut-ofifs, as well as thelead, the radii H\ H-, H^, etc., of the eccentric circles ordiameters of the corresponding valve circles…
Locomotives
