Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 96
ecessary in order that itmay be kept steam-tight. Referring to Fig. 33, whichis a plan view, the throttle lever Y is fitted with a latch1 that gears into the curved rack 2-3, in order to holdthe throttle in any required position. The latch i isoperated by a trigger 4, connected by the rod. The… … THROTTLE AND DRY PIPE 69 tbis dividing it into two branches to which the steampipes are connected. These connections, which arc all within the cmoke-box, are clearly illus-trated in Fig. 31, towhich reference isnow made. The steam pipes Iand 2 are connectedto each of the twobranches of the T-pipe…
Locomotives
