. It forms a rounded bottom to the ditch, suitablefor the reception of either of the ordinary sizes of farm drain-tile. The dirt is all dischargedat one side of the ditch, convenient for refilling. As the wheels are 10 in. broad, the machineworks on soft gnnind as well as hai-d, even where horses… … required depth. The cuttin<r-wheel cuts down the sules of the ditch, and a scoop just behindthe lowest part of the wheel pares oflf a layer of dirt, and causes it to pass upward under thecontrol of an endless apron, which retains the earth in the grooved periphery of the wheeluntil the dirt is…
