Fig. 3.—Multiple traverse table-drill. 186 DKlLLIXG-.MACiilXE.S, METAL … DRILLING-MACHIJSES, METAL. 187 cards were taken from an apparatus, a.s shown in Fig. 6, consisting of a cylinder of cast-iron,witii flange at the base, and bored out to receive a plunger. The area of this cylinder was 10sq. in. Near the bottom of the plunger three grooves ^\- in. deep were cut, and…
