Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 323
268 MECHANICAL ENGINEERING OF POWER PLANTS. … ENGINE FOUNDATIONS AND BED-PLATES 269 horizontal plane. Fig. 226 represents a standard bed-plateof this type, and Fig. 227 shows a section through the girder(see Fig. 182 also). A modification of the Corliss bed-plate is identified withthe name of Tangye of England, in which the cylinder over-hangs…
Mechanical engineering · Steam power plants
