e actionof water compressetlin a cylinder forminga continuation of thetool-carrier. In theinterior of this cylin-der there is a plungerwhich abuts againstthe column thatserves as a supportto the apparatus. Arotary motion is giventhe tool by a cog-wheel keved to the . , ^ n u i ^cvlinder and… … Fio. 16.—Hand-power drill.
