Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 268
Fig. 4.—Elevating deck ferr3--boat. Fio. 3.—Belt elevator is, in fact, composed of a series ofeach other by knuckle-joints. These-rollers at each point of attachment.The link, thus articulated, is in-troduced into a round or squareguide-way, in which it runs easi-ly, and follows all sinuosities…
Mechanical engineering
