the three elementary moving partsof which the engine is composed are, a pair of quarter-spheres A and B. with a circular diskPoi infinitesimal thickness interposed between them, the diameter of the disk being the sameas that of the sphere of which they are sectors. The straight edges of the sectors… … Fig. 5
