Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 320
he station-<^ ary disks ; thus the faces of the moving wheels seat (nearly) upon the bottom of theannular spaces of the stationary disks, andthe faces of the stationary disks seat (nearly)upon the bottom of the annular spaces ofthe wheels. In the central chamber, midwav between the partitions,… … Fig. 13.—Dow steam turbine.
Mechanical engineering
