Fig. 25.—Main bearing—section. surround the entire valve. The valve can be easily operated with one liand upon the smoothvalve-steni, when under full pressure of steam. The relief-valve is in the form of a steam-tight piston, which rests on shoulders even with the valve (not on the valve itself),… … FlO. 27.—The Biill triple-expansion enpine. kept in place by a stool spring at tlic haek. Fig. 25 is a section through tlie main bearing.showing tlie two bearings in a single casting, wilii tiie overhang at each end nearly lialanecdand reduced to a minimum l)y means of olTset liubs. Fig. 2(i is…
