Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 328
Valve. … Fig. 30.—The Ball and Wood compound engine. Light Co., of Newark. The size of the low-pressure cylinder is 13 in. and the high-pressure25 in., with a stroke of 16 in. It is rated at 300 hor.se-power. The Mcintosh & Seymour Engine is shown in Fig. 31. Fig. 32 shows a .sectional view ofthe valve…
Mechanical engineering
