Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 332
1- i(i. 40.—Valve and cylinder. … Fig. 41.—The Harrisburg compound engine. The extra heavy shaft and fly-wheel are supported between the bearings, avoiding the over-hang of the fly-wh(;el, as is tlie case in the center-crank type. One of the special features inthe Harrisburg tandem compound is the method of connecting the high and…
Mechanical engineering
