Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 348
Fig. 76. Fig. 77. On one side is formed a passage, B. communicating with the exhaust-pipe i? of the high-pressure cylinder, and a passage C opening into the pipe 6\ through which the steam passesto the low-pressure cylinder after having been reheated. The ends of the cylinders are closedby the…
Mechanical engineering
