Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 386
amped between two disks and rotated with itsedge projecting over a short vertical roller. A swiveling-roUer turns the flange down as theplate passes quite rapidly under it. This upper or swiveling roller is carried in a housingsupported by two parallel levers, which are actuated by worm-gearing and… … Figs. 3, 4.—Kents flanging-machine. 366 FLAX-MACHINES. head being flanged, giving a smooth, easv motion for the flow of the metal into its new form.The saddles carrying the two rollers are adjustable along the bed. thus making heads of vary-ing diameters without formers. No hole is necessary in the…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
