Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 380

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 380
ey can move independent ofthe frames, B, and wheels, G.While the frames, B, makeone revolution, the wheels, D,and the center wheels make two revolutions. This is caused by theaction of the weighted levers E. Their weight, or inertia, prevents themfrom passing around the center of the axis of the… … 938. PERPETUAL MOTION. Mercurial wheel. A is the screwturning on its two pivots; B is a cistern to be filled above the level of the lower aperture of the screwwith mercury; D is a reservoir,which, when the screw isturned round,, receives themercury which falls from thetop. A pipe conveys the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
