Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 413
is then moved the proper distance for the next tooth, andso on until finished. The cutter-head is adjustable at any angle for cutting bevel-wheels, thedegrees being marked on a graduated arc, no other change being required. There is also pro-vision for moving the cutter out of center eacli way, for… … Fig. 3.Figs. 2, 3. —Bilgrams bevel-gear cutter. which will corrocliy gear witli any wheel of the sot. Any wliool that gears correctly with thisrack must therefore also gear correctly with any other wheel of the set: and from this itfollows that if any number of wheels are made to gear correctly…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
