Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 64

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 64 — ethe crank pin upon its forward dead center, loosen the piston-rod nut, andscrew the piston into the crosshead until it is brought up against thefront head of the cylinder; after which screw up the nut until it touchesthe crosshead hub without jamming. Now place the crank pin upon itsopposite dead… … FIG. 55. head hub represents the total clearance of the cylinder, which should beadjusted by screwing the piston rod into the crosshead half of the amountof total clearance and tightening and the nut. This method is sufficiently accurate for all practical purposes if careis exercised not to disturb…

Steam-engines
