Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 422
Fig. 5.—Mcintosh and Seymour governor. for regulating the speed of the engine by centrifugal weights and opposing springs, whichcontrol the point of cut-off by swinging the eccentric across the shaft. The centrifugalweights are pivoted, and are pro-vided with inclined jaws. Whenthe weights move,…
Mechanical engineering
