Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 446
Fig. 27.—The Holmes binder in operation. … Fig. 29.—The ejector. 426 HARVESTING-MACHINES, GRAIN. sheaves and carry them back over upon the mechanism of the binder, as may occur with arotary ejector. The mechanism, except the needle when at rest, is placed above the table, andis seen in a general view in Fig. 30, which also exhibits a number…
Mechanical engineering
