FiG. 45.—Woods harvester ready for shipment. ward by the hand-lever e, with their respective connecting-rods, to adapt the position of thereel in relation to the grain, the sickle-bar, and the conveyer which receives the grain. At /is a lifter-spring so attached as to sustain a greater portion of… … Fid. 4C.—Milwaukee driviiip-pear. HARVESTING-MACHINES, GRAIN. 431 support, to render easy the manipulation of lever d. The levers have spring-latches, andmaintain the reel in any given position for the time being.
