Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)

Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 494

An illustration from Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics, 1892, leaf 494 — Fig. C—Lathe-tool. Dl». CUAMP COLL«R Dm HOLDIR. Fig. 8.—Turret-lathe tools. … Fig. 10.

Mechanical engineering

Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
