Fig. 3.—Section through cyhnder. comotives by the Committee of Sciences and Arts of the Franklin Institute, which caused itto be awarded a gold medal; It can be applied to locomotives having outside cylinders, without increasing the entire … Fig 3 —Compound locomotive breadth of the engines at the cvlinders bevond the restrictions made necessary by bridges,tunnels, and trains^ upon parallel tracks. The transfer of steam from the low to the high 488 LOCOMOTIVES. -pressure cylinder is effected by the shortest possible conduit. Tsimple,…
