Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 566
Fig. 6.—Daft moror. Fig. 7.—Diehl motor. provided with a pulley, and its end is bored so that the jDower can bo transmitted by belt orapplied directly, as when driving a fan. To avoid the necessity of belting, and at the same time do away with the presence of anauxiliary machine on the board for…
Mechanical engineering
