Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 1336
Fig. 610 diagram of magnets, flux, coil and inner core of weston instrument … Fig. 611view of movement of weston instruments 1308 Steam Engineering springs^ the angular movement of the coil depending onthe strength of the current in the coil and the strength ofthe field in which it is placed. To the coil is attached a pointer of aluminum, the wholebeing balanced so that the…
