Fig. 34.—Edeerton motor. Pig. 35.—Edgerton motor. Section. central prism of the same number of sides. Through the central axis of this prism, theshaft is placed longitudinally, and. as before stated, supported in bearings in the end capsof the motor. The outer or peripheral extremity of each of… … 3tj.- InimiscU motor Pig. 37.—Winding. shape, coinciding in curve with the inner concave surfaces of the pole pieces between whichit revolves. The helices are wound parallel with the axis of the armature, as in the Siemensshuttle armature, and each is complete in itself Similar ends of each helical…
