approximately the same length of stroke throughout, which is an impossibility in any machine in which the jaw is pivoted at one end only. The Blake-Marsden Crusher is another modification of the ordinary Blake crusher, in which the eccentric-shaft is placed at the extreme rear end of the machine,… … ORE-CRUSHING MACHINES. 577 The toggles are seated in the short arm of the lever which extends upward ; the long armprojects backward, and is pivoted at its end with the lower end of the pitman. The oscillat-ing Jaw is pivoted at the top, as in the ordinary Blake crusher. It is claimed that…
