hown projecting through the 688 PUMPS, RECIPROCATING. floor; this is made to fit any location or conditions. The rods connecting the bob withthe [)iimps and crank are made any size or length, depending on the depth of the shaft and itsdistance from the engine : these i-ods are supported by trucks… … Pig. 7.—The Allis geared mine pamp. tooth pinion and gear of such proportions that the engine will run at a fair rate of speedwhile the pump plungers move at a slow speed when running at rated capacity. Electric Pumps.—The numerous a{)|)lications of electricity to pumping purposes whichhave been…
