the boiler,throug-h a small opening into tiie (tyliudor. This forces the piston out to the mouth of thecylinder, where it is held by lugs from going further. When the pressure comes on thepiston, it forces the steam back into the boiler, but the pressure comes so quickly, and theopening is so… … Fig. :..—ThcSuuinUrs cliauutling machine. and cutting tools may be tipped backward for use in what is known as side-hill work. Astandard Ingersoll Eclipse rock drill of large size, 6 in. diameter of cylinder, is used, themachine being specially constructed for channeling purposes. Instead of a…
