Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 770
of the frontroller. To this plate is also bolted a gearing frame, with the bearing for the cross-shaft andbevel pinion. These plates, with the four stools, are bolted to the masonry foundation. Thetop framing, carrying the rollers at the top, as also the top main pinion shaft, is cast-iron,and it… … 742 EOLLS, BENDING. friction rollers. These are 12 in. broad, those at the sides being 10 in. in diameter, and atthe back 18 in. in diameter. They are so arranged that they transfer the pressure off theroller to the vortical standard. The inner rollers are each driven by a large spur-wheel, 3^in.…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
