Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 799
Horizontal circular saw 770 SAWS, WOOD. bottom wheel runs in a bath to lubricate and cool the saw. The upper wheel is providedwith a suspended bearing, with attached weight to keep the saw at a proper tension. The … Fk;. 7.—Band paw. saw passes between two guides and presses against a wheel which revolves with the saw,thus reducing the friction. The lower saw guide is inserted in the table, and the upperguide can be raised and lowered to suit the various de[)ths of work. SAWS, WOOD. In the consideration of…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
