el wheel, 49^ in. in diameter at pitch line, fast on themain shaft, tiius driving the knife wheel placed in the front of the machine. Thiswheel is 10 ft. in diameter, and is set in a round casing, with a flaring, square front, 10 ft.wide and the same height, which is made of i-in. steel plate. This… … Fig. 2.—Stealer carriage. 800 SHOVEL, RAILROAD SNOW. twelve radial plates, in the shape of an immense fan wheel. Upon the front of these radialplates are placed an inner and outer soi-ies of knives. These knives are pivoted on radialpins, and the surfaces of the knives being inclined to one…
