The lower floating frame carrying the bladedreel is attached in front to the main frame above it by draft rings at the corners, and ispressed down by a pair of strong spiral side springs, which occasion a successive reboundof each of the five blades downward after every recoil from the resistance… … Fig. 2.—Stalk cutter. 806 STEAM LOOP. steadily applied. To relieve the team from undue jerking under the chopping actiondescribed, the doubletree is connected by a spring to the draft rod of the machine. The cyl-inder is covered for safety from the knives, and the cover forms a box for ballast, to…
