Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 841
Fig. 5. The Batho furnace.Cross si-ction. … Fig. 6.—The Batho FurniKo. Pliui the gas entrance, the air port having a very steep pitch into the furnace of at least 8 in. ineverv foot. This arrangement guides the flame downward right onthe iiearth, and does awav with much of the sharp cutting action ofthe flame on the roof, which thus has t(j…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
