Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 86
Fio. 1.—Tube cleaner. BOLT-CUTTER. 71 connection, and the deposit from the tube is drawn through the unobstructed passage anddiscliarged from the mouth of the apparatus with a velocity sufficient to clean the tube towhich it is applied, discharging the contents out of the chimney-top. BOLT-CUTTER.… … FlQ. 1.—Bolt OVltttT. principal parts, as shown in Fig. 2. 1. The die-box. which is made of steel and contains thefour (lie-slots, in which the dies are accurately fitted and firmly held. 2. The ring, whichsurrounds the die-l)ox and receives the thrust or bearing of the dies when in operation.…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
