ke those of rebatingplanes, cutting across the stuff, each time taking a shaving from the full width of the stick,and each time leaving a clean, smooth cut, so that at any point at which the cutting isstopped the work is left clean and smooth. Of course, in sv:ch work as this it is desirable totake… … Fig. 6.—The Fay car-tenoninj; machine. of cut. The power to work these plane tenoning machines may be greatly increased by theuse of rack and pinion gears. It is seldom that the foot is used in driving such machinery,the arm being more delicate as regards the adjustment. II. Vertical Tenoning…
