on. In some of these, for work in drawer fronts and similarpieces, the cutting tools are in sliding frames, adjustable for the length of the pin or tenon ;the carriage bearing the material is moved vertically and lengthwise, automatically, cuttingat each movement of the crank wheel a pin and a… … Fig. 9.—Blind-slat tenoning machine.
