Fig. 6.—Staclcer at worli. 862 TllKESHING MACHINES. ous. This attachment is provided with a row of belts which intercept the sheaves of graindelivered by a man with a pitchfork haphazard into the receiver, down the shake-table ofwhich they are propelled by raking teeth fixed to its surface. This… … Fio. -Pitts thresher. the descending stream of grain, to retard its upper stratum wlienever it runs thicker thana determined gauge, while the shake-table uninterruptedly proj)els the lower stratum at aconstant rate of speed into the thresher. A gang of half-moon vibrating knives cut thebands of the…
