Fio. -Pitts thresher. the descending stream of grain, to retard its upper stratum wlienever it runs thicker thana determined gauge, while the shake-table uninterruptedly proj)els the lower stratum at aconstant rate of speed into the thresher. A gang of half-moon vibrating knives cut thebands of the… … Fig. 8.—Thresher and bagger. Appleby type, driven by one knotter shaft and one needle sliaft for both, by a chain beltfrom the neighboring shaker spindle of a thresher. When the thresher presents sufficientthreshed straw to fill the binder receptacles and trip either knotter, both are tripped…
