Motor-car principles; the gasoline automobile (1910)
Whitman, Roger B. (Roger Bradbury), 1875-1942 · New York, London, D. Appleton and Co. · leaf 267
Fig. 52. — Make-and-Break Wiring Diagram. Magneto and coil. Battery for starting. … Fig. 53. — Make-and-Break Wiring Diagram. Magneto ignition without coil. Starting on magneto. 241Automobiles
Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
