Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 278
ill find it still serviceable.If then, there be a leak, or the timer rotor be in engagement withone of the contacts, the current will rapidly run to waste. Ques. What i.: the action of dry cells? Ans. Dry cells, so called, are all of the open circuitvariety. That is to say, the generation of the… … Fig. 154.—^Wiring diagram showing connections for Remy magneto withseparate coil and battery; the figure illustrates also the order of firing. for a period on open circuit, or disconnected. A polarizedcell will show a low current register on the ammeter, but itsstrength may be restored more or…
