M. Vitrvvivs per Iocvndvm solito castigatior factvs cvm figvris et tabvla vt iam legi et intelligi possit (1511)
Vitruvius Pollio · Impressum Venetiis ... : Sumptu miraq[ue] diligentia Ioannis de Tridino alias Tacuino · leaf 80
inediuidatur re/liqua pars in partes tres,ex quibus vna imo folio detur, fecundum foliummediam altitudinem teneat,cauliculi eandem habeant altitudinem, e qui/bus folia nafcuntur proie£ta,vti abacum excipiant, qua» ex cauliculorumfoliis natsprocurrunt ad extremos angulos volutx, minorefq? helices… … a. modufuscx imi fcapicolunae funvptus b. uoluta c. folium d. flos c. cauliculif. abacus Suntautemquse iifdem columnis imponuntur capitulorugenera variisvocabulis nominata,quorum nec proprietates fymmetriarum nec columnarumgenusaliudnominarepoimmus,fed ipforum vocabula traducla& commutata ex…
Architecture · Machinery
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
