Liquid-Hydrogen-Fueled Aircraft (1973)

NON · leaf 15

An illustration from Liquid-Hydrogen-Fueled Aircraft, 1973, leaf 15 — INTEGRAL FUEL CONTAINMENT … 100 Percent 78 Percent Volume Utilization Volume Utilization The sketches shown here illustrate what to us appears to be the most critical design problem of LH2 aircraft: integral fuel containment. Todays technology contains the LH2 in insulated, cylindrical pressure vessels. Considering the…
