Putnam, G. R. (George Rockwell), b. 1865 · New York, J. Wiley & Sons; [etc.] · leaf 88
FIG. 22. MERCATOR PROJECTION OF NORTH PACIFIC OCEAN, SHOWING GREATCIRCLE ROUTES YOKOHAMA TO PUGET SOUND, AND YOKOHAMA TO HONOLULUAND THENCE TO SAN FRANCISCO. … FIG. 23. POLYCONIC PROJECTION OF PORTION OF NORTH PACIFIC OCEAN. C7n Poly conic Projection 73 straight lines on this projection is another defect, asby the plotting of bearings and angles on approachingthe land the positions of vessels are located on thechart; fortunately, however, the error due to…
Nautical charts
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
