Naval architecture: a manual on laying-off iron, steel, and composite vessels (1898)
Watson, Thomas Henry · London; New York: Longmans, Green and co., [etc.] · leaf 107
(0 CO tab … FLOORS AND DOUBLE BOTTOMS. 41 these points square to the dotted line w x placed in each section, andlay them off in the expansion plan from the top M N on their corre-sponding distances from the centre. Make R 0 the width of the keelbar and parallel to the top. Then a curve passed through each set…
Naval architecture -- Handbooks, manuals, etc · Naval architecture · Ships, Iron and steel
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
