The naval constructor: a vade mecum of ship design for students, naval architects, shipbuilders and owners, marine superintendents, engineers and draughtsmen (1904)
Simpson, George, 1865- · New York, D. Van Nostrand company ; London, K. Paul, Trench, Trübner & co., ltd. · leaf 220
f the Stresses 205 bar is known as the modulus of elasticity, and may also be expressedas the tensile force, which, when applied, will double the barslength, and of course may be different in the same material whensubjected to tension, compression or shear. Permanent Set. — If a bar be extended or… … Fig. 56. Distance*. Ak i: \. Moments. Si = 4.40 X 2.04 = 80.40 S2 = 1.75 X 1.48 4.73 >. = 2.00 X 1.64 = 6.56 s4 = 8.75 X 2.44 = 84.80 Moment of Inertia /Section Modulus Z 85.085:15 85.08= 16.5. The Moment of Inertia of a section or body is a mathematicalquantity used to calculate the strength of…
Shipbuilding · Marine engineering
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
