Steel ships, their construction and maintenance : a manual for shipbuilders, ship superintendents, students, and marine engineers (1901)
Walton, Thomas · London : Charles Griffin & Co. ; Philadelphia : Lippincott · leaf 99
hus, while the stresses increasein proportion to the distance of the unit of area from the neutral axis,the moments of these stresses, or moments of resistance, increase in pro-portion to each stress multiplied by its respective leverage from the neutralaxis. The sum of all these moments of… … Fig. 35.—The arrowed lines in the upper half of the bar represent the resistance ofthe material to compression, or compressive stresses. The arrowed lines in,;thelower half represent the resistance to elongation, or tensile stresses. The calculation should be :— Let R = stress at distant edge of…
Naval architecture · Ships, Iron and steel
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
