The naval constructor: a vade mecum of ship design for students, naval architects, shipbuilders and owners, marine superintendents, engineers and draughtsmen (1904)
Simpson, George, 1865- · New York, D. Van Nostrand company ; London, K. Paul, Trench, Trübner & co., ltd. · leaf 325
eye as shown by Fig. 101. observing that in the fore body abovethe waterline the widths are kept parallel, which necessitatesworking stealers in the under-water body at the fore end. Run-ning these plate widths parallel gives a straight, sharp appearanceto the sight edges, a very important point… … FIQ. 192. Shell Plating 311 accentuate and exaggerate the bluff lines. In addition it enablesus to work the narrow plates where the form is most difficult towork. In the after body different conditions exist, the mostimportant plate line being that which ends at the oxter, so that itis only…
Shipbuilding · Marine engineering
