om =half the stern depth above base. Siding of hog = twice thesiding of keel. Moulding of hog = .4 of the siding. Scarphs ofkeel, etc. = 4§ times the siding. Spars.— Diameter of Mast, \ . . per foot of length. Gaff, Ty ... Topsaif Yard, \ Boom, Ty . . Spread Yard, \ Bowsprit, f . Sheer. —Gigs sheer… … 422 The Naval Constructor Sails. — The sail area may with advantage be based on themidship section area measured to underside of thwarts multipliedby 12. i x 12 = sail area. Scantlings. — The scantlings may be as given in the tablewhich shows the requirements for boats of the Royal Navy, orthese…
