A new manual of perspective: containing remarks on the theory of the art, and its practical application in the procudtion of drawings ... Illustrated by numerous engravings (1849)
Whittock, Nathaniel · London, A. Hall & Co. · leaf 47
ster-hall as for thepassage of a private residence. Operation 6. — To draw a circle in per-spective. To show the perspective of a circle, it willfirst be necessary to draw a circle the sizerequired, and enclose it in a square. Divide 44 MANUAL OF PERSPECTIVE. this square into compartments, as seen… … lines are also drawn from each angle of thesquare, to increase the intersections, in thediagram before us. The upper part of thesquare that contains the circle forms the baseline of the perspective drawing. From the MANUAL OF PERSPECTIVE. 45 ends of the upright lines forming the divisionsof the…
Perspective
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
